Optical Parameters:
| Focal Length | 44mm/132mm Dual FOV | Distortion | <3% (44mm) <1% (132mm) |
| F/# | 0.8(44mm)/1.1(132mm) | Back Working Distance (BWD) | 14mm |
| Operating Wavelength Range | 8 to 12µm | MTF / at 20cy/mm | >35% at all zoom positions |
| Average Transmission | 80% 8 to 12µm | Minimum Focus Range | 3m/15m |
Mechanical Specification:
| Max. Dimensions (Diameter x Length) | Φ160×169.3 | Operating Temperature Range | -20℃ to +60℃ |
| Weight | 2300g | Storage Temperature Range | -45℃ to +85℃ |
| Sealing Grade | IP67 Front Lens |
Electronics:
| Focus Time | <7s | Driving Voltage | DC12V (0.5A average) |
| Switch Time | <3s | Lens Control | RS485 Upon Request |
FOV-Sensor Size:
| FOV(HXV) | 384x288 | 640x480 |
| 17μm | 2.83°×2.12°/8.5°×6.4° | 4.72°×3.54°/14.1°×10.6° |
| NFOV to WFVO | ||
Drawing:
