Optical Property
| Focal Length | 25 to 75mm | Distortion | <7% (25mm) <1% (75mm) |
| F/# | 1.2 | Back Working Distance (BWD) | 10.3mm |
| Operating Wavelength Range | 8 to 12µm | Minimum Focus Range | 1.5m/5m |
| Average Transmission | 80% 8 to 12µm |
Mechanical Property
| Max. Dimensions (Diameter x Length) | Φ82×107.5 | Operating Temperature Range | -20℃ to +60℃ |
| Weight | 600g | Storage Temperature Range | -45℃ to +85℃ |
| Sealing Grade | IP67 Front Lens |
Electronic Property
| Focus Time | <5s | Focus Voltage | DC6V (0.5A average) |
| Zoom Time | <5s | Zoom Voltage | DC6V (0.5A average) |
| Lens Control | Upon Request |
| FOV(H X V) | 384×288 | 640×480 |
| 17μm | 5°×3.7° to 15°×11° | 8.3°×6.2° to 24°×19° |
| NFOV to WFVO | ||
